Design Features of 6200 Series Bearing
This Bearing is constructed with a single row of balls, a deep groove raceway in the outer ring, and is known for its robustness and durability. It can offer a highly adaptable and efficient solution for a multitude of mechanical applications.
What Benefits Can This Bearing Provide?
High load-carrying capacity: It can support heavier radial loads compared to other types of ball bearings.
Versatility: Capable of handling both radial and axial loads simultaneously.
Low friction: It’s designed to operate with minimal friction, making them ideal for high-speed applications.
Simplified maintenance: Typically require less maintenance compared to other types of bearings, making it ideal for set-and-forget operations.
What Can This Bearing Be Used for?
The Bearing is suitable for a wide range of applications due to its design and load handling capabilities, such as:
Electric Motors: Commonly used in both industrial and smaller, household motors.
Automotive: Often found in car transmissions, clutch systems, and wheel hubs.
Industrial Machinery: Used in a variety of machines including conveyors, pumps, and compressors.
Home Appliances: Found in washers, dryers, and other household equipment.
| Inquiry | Type | Bore | Outer | Width | Width | Radius | Load Rating(N) | Max speed | ||
|---|---|---|---|---|---|---|---|---|---|---|
| Diameter | Diameter | B | B1 | rs（min） | Dynamic | Static | Grease | Oil | ||
| d （mm） | D（mm） | mm | mm | （mm） | Cr | Cor | *1000RPM | *1000RPM | ||
| 6210 | 50 | 90 | 20 | 20 | 2 | 29800 | 18610 | 7.10 | 8.50 | |
| 6209 | 45 | 85 | 19 | 19 | 2 | 27790 | 16300 | 7.70 | 9.20 | |
| 6208 | 40 | 80 | 18 | 18 | 2 | 24730 | 14330 | 8.30 | 10 | |
| 6207 | 35 | 72 | 17 | 17 | 2 | 21810 | 12360 | 9.20 | 11 | |
| 6206 | 30 | 62 | 16 | 16 | 1.50 | 16530 | 9080 | 11 | 13 | |
| 6205 | 25 | 52 | 15 | 15 | 1.10 | 11900 | 7390 | 13 | 15 | |
| 6204 | 20 | 47 | 14 | 14 | 1 | 10910 | 5360 | 15 | 17 | |
| 6203 | 17 | 40 | 12 | 12 | 0.60 | 8130 | 3850 | 17 | 21 | |
| 6202 | 15 | 35 | 11 | 11 | 0.60 | 6490 | 3000 | 20 | 24 | |
| 6201 | 12 | 32 | 10 | 10 | 0.60 | 5770 | 2450 | 22 | 27 | |
| 6200 | 10 | 30 | 9 | 9 | 0.60 | 4340 | 1920 | 24 | 29 | |
| 629 | 9 | 26 | 8 | 8 | 0.30 | 4575 | 1983 | 28 | 34 | |
| 628 | 8 | 24 | 8 | 8 | 0.30 | 3333 | 1423 | 28 | 34 | |
| 627 | 7 | 22 | 7 | 7 | 0.30 | 3287 | 1379 | 30 | 36 | |
| 626 | 6 | 19 | 6 | 6 | 0.30 | 2336 | 896 | 32 | 40 | |
| 625 | 5 | 16 | 5 | 5 | 0.30 | 1729 | 675 | 36 | 43 | |
